Specification
Brand
Aurora
Item Number
AURCB-5
Bore Size
5/16 inch
Thread Size
5/16-24
Thread Direction
Left Hand
Construction
Two-Piece
Body Material
Low-Carbon Steel
Ball Material
Sintered Steel, Heat Treated, Oil Impregnated
Finish
Zinc Oxide
Misalignment Angle
22 degrees
Static Load Capacity
3,068 lbs
Weight
0.08 lbs
Description
The Aurora CB Series Economy Steel Rod End is designed for general-purpose applications, offering a 5/16-inch bore and 5/16-24 left-hand male thread. Constructed from durable steel with a protective zinc oxide finish, this two-piece rod end combines a low-carbon steel body with a sintered steel, heat-treated, oil-impregnated ball. It provides a misalignment angle of 22 degrees and a static load capacity of 3,068 lbs, ensuring reliable performance in various mechanical linkages.
Disclaimer
Product specifications and availability are subject to change without notice. Please verify all information before making a purchase.
