Specification
Brand
Aurora
Item Number
AW-6
Bore Size
0.375 in (3/8 in)
Thread Size
3/8-24 UNF-3B
Thread Hand
Right Hand
Static Load Rating
9,544 lbf
Head Diameter
1 in
Housing Width
0.406 in
Ball Diameter
0.719 in
Misalignment Range
12 degrees
Housing Material
Heat-treated alloy steel with protective coating
Ball Material
Alloy steel
Thread Length
0.937 in
Total Height
2.125 in
Weight
0.152 lb
Description
The Aurora AW-6 is a high-strength female rod end designed for demanding applications. Featuring a 3/8-inch bore and 3/8-24 right-hand female thread, this rod end offers a spherical design for enhanced flexibility and load distribution. Constructed from heat-treated alloy steel with a protective zinc oxide finish, it ensures durability and corrosion resistance. With a static load rating of up to 9,544 lbf and a misalignment range of 12 degrees, the AW-6 is ideal for various mechanical and industrial uses.
