Specification
Brand
Aurora
Item Number
AURXAM-8T-2
Bore Size
0.500 in (12.7 mm)
Thread Size
3/4-16 UNF-3A
Thread Direction
Right Hand
Thread Length
1.750 in (44.45 mm)
Ball Width
0.750 in (19.05 mm)
Housing/Race Width
0.562 in (14.27 mm)
Outside Diameter
1.750 in (44.45 mm)
Misalignment Angle
11.8°
Static Load Capacity
40,572 lbs (180,461 N)
Material
Alloy Steel (Body and Ball), Low Carbon Steel (Race)
Finish
Zinc Oxide
Liner Material
PTFE (AT1400 PTFE/Dacron Laminate)
Heat Treatment
Yes (Body and Ball)
Ball Plating
Hard Chrome
Approximate Weight
0.60 lbs (273 g)
Maximum Operating Temperature
121°C (250°F)
Construction
Three-Piece
Maintenance
Maintenance-Free
Series
XAM Heavy Duty Shank Series
Description
The Aurora XAM-8T-2 Male Rod End is a high-strength, three-piece rod end designed for demanding applications. It features a 1/2-inch bore and a 3/4-16 right-hand male thread. Constructed with a heat-treated alloy steel body and race, and a hard chrome-plated alloy steel ball, this rod end ensures durability and performance. The PTFE liner provides maintenance-free operation, while the zinc oxide finish offers corrosion resistance. Ideal for applications requiring high static load capacity and misalignment accommodation.
Disclaimer
Product specifications and availability are subject to change without notice. Please verify all information before purchase.
