Specification
Brand
Aurora
Item Number
CM-12
Bore Size
0.7500 in (3/4 in)
Thread Size
3/4 - 16 UNF
Thread Type
Right Hand
Static Load Rating
14,207 lbs
Housing Material
Low Carbon Steel, Protective Coated for Corrosion Resistance
Ball Material
Alloy Steel, Heat Treated, Hard Chrome Plated
Length Through Bore
0.875 in
Head Diameter
1.750 in
Head Width
0.593 in
Thread Length
1.750 in
Misalignment Angle
24°
Lubrication
Non-Relubricatable
Weight
0.57 lbs
Description
The Aurora CM-12 is a general-purpose economy male rod end designed for versatile applications. Featuring a 3/4-inch bore and 3/4-16 UNF right-hand male thread, this rod end is constructed with a low carbon steel body, protective coated for corrosion resistance. The alloy steel ball is heat-treated and hard chrome plated, ensuring durability and performance. With a static load rating of 14,207 lbs and a misalignment angle of 24 degrees, the CM-12 is suitable for various mechanical linkages requiring reliable articulation.
