Specification
Material
A356 Aluminum
Intake Port Volume
335cc
Exhaust Port Volume
135cc
Combustion Chamber Size
122cc
Valve Spring Pocket Diameter
1.725 O.D
Max Valve Spring Pocket Machining
1.750 O.D
Deck Thickness
.750
Minimum Bore Diameter
4.250
Flat Mill
.006 Per CC / Maximum 114cc
Angle Mill
.009 Per CC / Maximum 104cc
Spark Plug Dimensions
14mm x .750 w/ Gasket Seat
Part Length
24.9
Part Width
11.4
Part Height
8.25
Brand
Air Flow Research
Item Number
AFR3001
Description
The Air Flow Research BBC 335cc Enforcer Cylinder Head 122cc Assembled offers precision and performance for your big block Chevy. With expertly designed 2.250 in/1.880 in valves and 1.550 in springs, this aluminum head ensures optimal airflow and combustion. Perfect for those who demand efficiency and power from their engine builds.
