Aces Fuel Injection - AFIAF2018

The Aces Fuel Injection AFIAF2018 Fuel Pressure Regulator is engineered for high-performance electronic fuel injection (EFI) systems. Constructed from billet anodized T6 aluminum, it offers durability and resistance to corrosion. The regulator features a composite fiber-reinforced diaphragm compatible with E85, gasoline, and diesel fuels. It maintains a 1:1 boost-to-vacuum ratio, ensuring consistent fuel pressure under varying engine loads. The unit includes two -8 AN ORB side inlet ports and one -6 AN ORB return port, accommodating various fuel system configurations. Additionally, it has a 1/8” female NPT front fuel pressure gauge port with a plug for easy monitoring. The adjustable pressure range is 35-78 PSI, allowing fine-tuning to specific engine requirements. The package comes complete with a mounting bracket and stainless hardware for straightforward installation.
