Specification
Brand
Wix Racing Filters
Item Number
WIX51515R
Style
Spin-On Lube Filter
Service
Lube
Type
Full Flow
Media
Enhanced Cellulose
Height
5.17 in (131 mm)
Outer Diameter Top
3.6 in (91 mm)
Thread Size
3/4-16
By-Pass Valve Setting-PSI
8-11 psi
Anti-Drain Back Valve
Yes
Max Flow Rate
28 GPM
Nominal Micron Rating
61
Gasket Outside Diameter
2.834 in (72 mm)
Gasket Inside Diameter
2.462 in (63 mm)
Gasket Thickness
0.200 in (5 mm)
Brand
Wix Racing Filters
Item Number
WIX51515R
Style
Spin-On Lube Filter
Service
Lube
Type
Full Flow
Media
Enhanced Cellulose
Height
5.17 in (131 mm)
Outer Diameter Top
3.6 in (91 mm)
Thread Size
3/4-16
By-Pass Valve Setting-PSI
8-11 psi
Anti-Drain Back Valve
Yes
Max Flow Rate
28 GPM
Nominal Micron Rating
61
Gasket Outside Diameter
2.834 in (72 mm)
Gasket Inside Diameter
2.462 in (63 mm)
Gasket Thickness
0.200 in (5 mm)
Brand
Wix Racing Filters
Item Number
WIX51515R
Style
Spin-On Lube Filter
Service
Lube
Type
Full Flow
Media
Enhanced Cellulose
Height
5.17 in (131 mm)
Outer Diameter Top
3.6 in (91 mm)
Thread Size
3/4-16
By-Pass Valve Setting-PSI
8-11 psi
Anti-Drain Back Valve
Yes
Max Flow Rate
28 GPM
Nominal Micron Rating
61
Gasket Outside Diameter
2.834 in (72 mm)
Gasket Inside Diameter
2.462 in (63 mm)
Gasket Thickness
0.200 in (5 mm)
Description
The Wix Racing Filters Performance Oil Filter Ford/Mopar 3/4-16 is engineered for superior engine protection in high-performance racing environments. Utilizing enhanced cellulose media, it effectively captures contaminants as small as 10-12 microns, removing up to 94% more dirt than traditional filters. The robust steel canister and black paint finish ensure durability under extreme conditions. Equipped with an anti-drainback valve and a bypass valve setting of 8-11 psi, this filter maintains optimal oil flow and pressure, safeguarding your engine during intense racing applications.
Disclaimer
This product is designed for racing applications only and is not intended for street use. Ensure compatibility with your vehicle before installation.
